Dimensions and Specifications
Hako-Core Specifications
Physical Dimensions
| Dimension |
Measurement |
| Length |
34.0 in (863.6mm) |
| Width |
17.25 in (438.15mm) |
| Height |
6.875 in (174.6mm) |
Storage Capacity
- 2.5" SSD/HDD: Up to 36 drives (with 12-SSD backplanes)
- 3.5" HDD: Up to 36 drives (with 4-HDD backplanes)
- Mixed Configuration: Combination of 2.5" and 3.5" drives
Weight Specifications
| Configuration |
Weight |
| Minimal Setup |
20 lbs |
| 3 fans, 3 cages & PCBs, no drives |
|
| Standard Setup |
25 lbs |
| 3 fans, 9 cages & PCBs, no drives |
|
| Fully Loaded |
~35 to ~90 lbs |
| 3 fans, 9 cages & PCBs, 42 HDD, 6 SSD |
(depending on drives used) |
Drive Power Capability
| Configuration |
Power Output |
| Single Powerboard |
600 Watts |
| Dual Powerboards |
1,200 Watts |
Motherboard Support
The Hako-Core supports a wide range of motherboard form factors:
- Mini-ITX
- Micro ATX
- ATX
- EATX (Extended ATX)
Fan Support
| Location |
Quantity |
Notes |
| Included Fans |
3 fans |
Pre-installed in chassis |
| Additional Front |
Up to 3 more |
Requires removal of front drive cages |
| Additional Rear/Middle |
Up to 6 more |
Requires removal of respective drive cages |
| Total Maximum |
9 fans |
With appropriate cage removal |
Power Supply Support
- Form Factor: ATX standard
- Maximum Length: 200mm
- Connector Requirements: Standard ATX power connectors
- Recommended Wattage: 750W+ for full configuration
Airflow Design
- Front-to-rear airflow pattern
- Positive pressure configuration recommended
- Variable speed control through motherboard or fan controller
Materials
- Construction: Powder Coated Aluminum
- Finish: Durable powder coating for long-lasting protection
- Mounting: Standard rack-mountable 4U form factor
Hot-Swap Support
- All drive bays support hot-swappable operation
- SAS/SATA compatibility across all bays
- Individual drive power and data connectivity
Hako-Core Mini Specifications
Physical Dimensions
| Dimension |
Measurement |
| Length |
34.0 in (863.6mm) |
| Width |
17.25 in (438.15mm) |
| Height |
6.875 in (174.6mm) |
Storage Capacity
- 2.5" SSD/HDD: Up to 36 drives (with 12-SSD backplanes)
- 3.5" HDD: Up to 36 drives (with 4-HDD backplanes)
- Mixed Configuration: Combination of 2.5" and 3.5" drives
Weight Specifications
| Configuration |
Weight |
| Minimal Setup |
20 lbs |
| 3 fans, 3 cages & PCBs, no drives |
|
| Standard Setup |
25 lbs |
| 3 fans, 6 standard cages + 2 mini cages & PCBs, no drives |
|
| Fully Loaded |
~35 to ~90 lbs |
| 3 fans, 6 standard cages + 2 mini cages & PCBs, 42 HDD, 6 SSD |
(depending on drives used) |
Power Capability
| Configuration |
Power Output |
| Single Powerboard |
600 Watts |
Motherboard Support
The Hako-Core Mini supports a wide range of motherboard form factors:
- Mini-ITX
- Micro ATX
- ATX
- EATX (Extended ATX)
Fan Support
| Location |
Quantity |
Notes |
| Included Fans |
3 fans |
Pre-installed in chassis |
| Additional Front |
Up to 3 more |
Requires removal of front drive cages |
| Additional Rear/Middle |
Up to 6 more |
Requires removal of respective drive cages |
| Total Maximum |
9 fans |
With appropriate cage removal |
Power Supply Support
- Form Factor: ATX standard
- Maximum Length: 200mm
- Connector Requirements: Standard ATX power connectors
- Recommended Wattage: 750W+ for full configuration
Airflow Design
- Front-to-rear airflow pattern
- Positive pressure configuration recommended
- Variable speed control through motherboard or fan controller
Materials
- Construction: Powder Coated Aluminum
- Finish: Durable powder coating for long-lasting protection
- Mounting: Standard rack-mountable 4U form factor
Hot-Swap Support
- All drive bays support hot-swappable operation
- SAS/SATA compatibility across all bays
- Individual drive power and data connectivity
